Mermaid diagrams are a popular way to create diagrams in markdown. They are used in many projects, including in GitHub Markdown. Since there are so many examples of mermaid diagrams in the wild,

it is not surprising that LLMs are pretty good at generating them.

Mermaid diagrams in Markdown

Mermaid supports a number of diagram types and quite a few options to control the appearance of nodes and edges. You can try out different diagrams in the Mermaid playground

Here is a simple example of a flowchart:

```mermaid
graph TD
    A[Start] --> B{Is it?}
    B -->|Yes| C[OK]
    B -->|No| D[Not OK]
    C --> E[End]
    D --> E
```

This markdown will be rendered as a flowchart in preview mode (and in GitHub!):

Syntax errors

One issue with mermaid is that… syntax matters and LLM sometimes get it wrong. Let’s introduce a syntax error in the example above.

```mermaid
graph TD
    A[Start] --> B{Is it?}
    B ->|Yes| C[OK]
    B -->|No| D[Not OK]
    C --> E[End]
    D --> E
```

Now mermaid fails to parse and the diagram is not rendered:

Parse error on line 3:
...--> B{Is it?}    B ->|Yes| C[OK]    B
----------------------^
Expecting 'SEMI', 'NEWLINE', 'EOF', 'AMP', 'START_LINK', 'LINK', 'LINK_ID', got 'MINUS'

In most cases, the LLM is able to fix the syntax error and generate a valid diagram using the error message.

Automatic repair

We have added a “repairer” in system.diagrams system prompt. The repairer looks for mermaid code blocks in the output and tries to parse them. If it the diagram has parse errors, the repairer adds a message to the chat to fix those.

Here is a trace of a simple script that generates a diagram from any code.

def("CODE", env.files)
$`Generate a class diagram using mermaid of the code symbols in the CODE.`

We run the cli with the mermaid.genai.mjs script and the runpromptcontext.ts file.

genaiscript run mermaid packages/core/src/runpromptcontext.ts

First attempt

The script generates a prompt with the code and the instructions to generate a diagram.

┌─💬 github:gpt-4.1 ✉ 2 ~↑9.2kt
┌─📙 system
│## Safety: Jailbreak
│... (18 lines)
│Use clear, concise node and relationship labels.
│Implement appropriate styling and colors to enhance readability.
┌─👤 user
│<CODE lang="ts" file="packages/core/src/runpromptcontext.ts">
│import debug from "debug"
│const dbg = debug("genaiscript:prompt:context")
│// cspell: disable
│import {
│    PromptNode,
│... (1202 lines)
│        env,
│    })
│    return ctx
│}
│</CODE>
│Generate a class diagram using mermaid of the code symbols in the CODE.

```mermaid
classDiagram
    %% Main context classes and interfaces
    class ChatTurnGenerationContext {
        <<interface>>
        +node: PromptNode
...
    %% Highlights to show this is a function producing a context with many callable methods.
    class createChatGenerationContext,createChatTurnGenerationContext highlightFunction;
    classDef highlightFunction fill:#f5f,stroke:#333,stroke-width:1.5px;
```
This diagram summarizes the main types, classes, and their relationships from `runpromptcontext.ts`. The context factories (`createChatGenerationContext`, `createChatTurnGenerationContext`) produce context "objects" rich in methods. Some utilities and dependencies are shown for structure clarity.

└─🏁  github:gpt-4.1 ✉ 2 7418ms ⇅ 9.7kt ↑8.8kt ↓892t 2.47¢

Syntax error detected, repairer activated

The mermaid diagrem generated has a syntax error.

Parse error on line 107:
...hatGenerationContext,createChatTurnGener
-----------------------^
Expecting 'NEWLINE', 'EOF', 'SQS', 'STR', 'DOT', 'GENERICTYPE', 'LABEL', 'STRUCT_START', 'STRUCT_STOP', 'STYLE_SEPARATOR', 'ANNOTATION_END', 'ALPHA', 'AGGREGATION', 'EXTENSION', 'COMPOSITION', 'DEPE…

The repairer enters the game and responds to the assistant with a message to fix the error. The entire chat conversation is sent back to the LLM , including the error message.

┌─💬 github:gpt-4.1 ✉ 4 ~↑10.5kt
┌─📙 system
│...
┌─👤 user
│...
│Generate a class diagram using mermaid of the code symbols in the CODE.
┌─🤖 assistant
│```mermaid
│...
│```
┌─👤 user
│I found syntax errors in the mermaid diagram. Please repair the parse error:
│Parse error on line 107:
│...hatGenerationContext,createChatTurnGener
│-----------------------^
│Expecting 'NEWLINE', 'EOF', 'SQS', 'STR', 'DOT', 'GENERICTYPE', 'LABEL', 'STRUCT_START', 'STRUCT_STOP', 'STYLE_SEPARATOR', 'ANNOTATION_END', 'ALPHA', 'AGGREGATION', 'EXTENSION', 'COMPOSITION', 'DEPE…

The LLM repairs the diagram

In this case, the LLM is able to repair the diagram and generate a valid mermaid diagram.

```mermaid
classDiagram
    %% Core Context Interfaces and Classes
    class ChatTurnGenerationContext {
        <<interface>>
...
    %% Factory highlighting (removed previous classDef/annotations for compatibility)
```
This diagram removes invalid classDef and annotation syntax and corrects relationship/arrows for Mermaid compatibility.

└─🏁  github:gpt-4.1 ✉ 4 3741ms ⇅ 10.3kt ↑9.9kt ↓457t 2.34¢

The repaired diagram

Finally, the repaired diagram is returned to the user:

Can I parse mermaid diagrams myselft?

Yes, you can use parsers.mermaid to parse mermaid diagrams in your scripts programmatically.
